Equipment

A high resolution 3D printing system based on linear motor translation stages. The whole system is built on a granite platform that is housed on a vibration-isolated optical table.

Minimum incremental motion: 1 nm

Bidirectional repetability: 0.1 μm

Other features: equipped with microscope camera and electrohydrodynamic printing module

Tissue Scribe is a single nozzle 3D bioprinter. This printer can print a variety  of materials, including gelatin, Gelatin-MA, alginate, chitosan, collagen, silicone rubber, PDMS, pluronic, etc.

Printing volume: 5.9 liters

Print size: 245 x 197 x 122 mm / 9.6 x 7.8 x 4.8 inches

Printing accuracy: 6K (5,760 x 3,600 pixels)

A custom-built Helmholtz coil system that consists of a NI voltage output module, six analog power supplies. It is controlled by LabView program to generate arbitrary magnetic field.

Three-axis magnetic field strength: 100 Gs

Magnetic field uniformity: < 0.25%

Usable space: 57 X 112 X 184 mm

40X-1000X with four extreme widefield magnification settings

Equipped with 18.0 MP HD recording camera

Four M204 potentiostat/galvanostat modules (+/- 400 mA maximum current, +/- 20V compliance voltage)

One FRA32M electrochemical impedance spectroscopy (EIS) module.

Keithley DMM6500 multimeter

Rigol DP 2031 three-channel programmable DC power supply

VGM vector/magnitude gauss meter

Sensepeed proble station

DZF-6020 vacuum oven

NE-1000 syringe pump system

VEVOR incubator

SCK-300P spin coater

Genie2 vortex mixer

Cole-Parmer ultrasonic cleaner

Ohaus Guardian 3000 hotplate-stirrer

Intelligent HT-224 analytical laboratory balance
